Battery variants and production
The Reention EEL IE battery can be built in various configurations, according to the customer's requirements. You can choose from the capacities below, or a custom capacity can be arranged on request.
36V 17.5Ah 630 Wh - 10S5P, 3500mAh Samsung cells, LG
48V 14Ah 672Wh - 13S4P, 3500mAh Samsung cells, LG
Custom
Are you a manufacturer or do you need batteries in different quantities? We make high quality custom batteries tailored to your requirements. Whether you need a smaller series or larger production, we offer you the right solution.
BMS specifications
| Ordinary BMS | Smart BMS | |
| Nominal voltage | 36V/48V | 36v |
| Series configuration | 10s, 13s | 10s |
| Min. voltage | 2.8V/ Cell | 2.8V/ Cell |
| Max. charging current | 4a | 4a |
| Max. discharge current | 20a | 20a |
| Balancing cells | Yes | Yes |
| Cut-off temperature | 65 ° C | Custom -made |
| Basic protection | Yes | Yes |
| A separate output for charger | Not | Yes |
| Can Communications | Not | Yes |
| Smart charger | Not | Yes |
| Diagnostics | Not | Yes |
