BISOL Premium are manufactured according to the highest industry standards
Components and materials used in the manufacture of materials that are pre-certified, tested and meet the highest quality standards are provided to us by established suppliers. Bisol modules, based on strict quality control criteria at each step of the production process, continue to provide long-term reliable operation with excellent power output and energy yield.
Known for their excellent work
Bisol Premium photovoltaic modules are known for their excellent performance, superior quality, high energy ripples and negligible degradation, enabling efficient and long-term operation of solar power plants.
Basic characteristics:
designed and produced in Slovenia,
an appropriately certified product,
up to 13% higher actual reheous than anticipated,
exclusively positive power output tolerances,
extremely low degradation,
high efficiency at low lighting.
Easy installation on multiple types of roofs
The cells are easily mounted on several types of roofs using modular BISOL EasyMount solar structures.
Slanted roofs
The common points of BISOL EasyMount's stretcher structures for sloping roofs are simplicity to save your precious time, durability, resistance in the most challenging weather conditions and flexibility to suit your specific preferences. You can choose from BISOL four smart supporting structures for oblique roofs that meet your needs to build a solar power plant on your roofing – corrugated roofs, trapezoidal metal roofs or other steel, wooden or even concrete structures.
Quick Rail - DOWNLOAD FILE or you WATCH VIDEO
Robust Bolt - DOWNLOAD FILE or you WATCH VIDEO
hook - DOWNLOAD FILE or you WATCH VIDEO
BISOL BIPV - In-roof integrated FN solution
Flat roofs
When preparing a photovoltaic system on your roof level or any other horizontal surface, it is extremely important that you have different configuration and layout options for optimal use of space, allowing maximum capacity and minimising the material, cost and time required for installation.
Elegant HDPE 200 -DOWNLOAD FILE or you WATCH VIDEO
Slim BASE & Twin Slim BASE -DOWNLOAD FILE or you WATCH VIDEO
Alpine TRIANGLE -DOWNLOAD FILE or you WATCH VIDEO
Choose one of the three reliable and flexible BISOL EasyMount load-bearing structures for any residential, commercial or even industrial project.
Electrical properties
| Peak power P | 330 W |
| voltage of open terminals U | 42.9 V |
| Peak power voltage U | 35.3 V |
| Short-term current I | 9.95 A.A. |
| Peak power flow | 9.35 A.A. |
| Module conversion efficiency | 20.2% |
| Maximum system voltage | 1000 V (Class A) |
Mechanical properties
| Dimensions | 1,649x991x35mm |
| Weight | 18.3 kg |
| Peak power voltage U | 60 serial (156x156mm) |
| Monocrystalline cells | aluminium |
| Glass | 3.2mm anti-reflex, tempered |
| Mechanical resistance | hail / fi 25mm / 83 km/h |
